Aluminium Case 20W 30W 50W 80W 100W LED Street Light Housing 20W Driverless LED Street Light
The power of this Street Led Lamp is 20w 30w 50w 80w 100w. The lumen of the Led Street Lamp is 100lm/w-110lm/w optional.
The light source uses Epistar 2835 or OSRAM 2835, high quality and long lifetime.
We provide 3 years warranty for this SMD led street light.
Newest design!!! Meet your difference requirements!
We believe the model is a good choose for you if you are looking for led street light.
What is LED street light?
LED street light refers to the street lamp made with LED lamps. It has the unique advantages of high efficiency, safety,
energy saving, environmental protection, long life, fast response and high color rendering index. It is of great significance
for urban lighting energy saving.
| Model NO. RYGHDOBSLZC20W |
| | Wattage | 20 Watt |
| Voltage | AC 180-300V |
| Certificate | CE, RoHs |
| Lumen | 100-110lm/w |
| Power Factor | >0.98 |
| Life Time | >50000 Hours |
| Size | 260*110*56mm |
| Chip | 2835 |
| CRI: | 80 |
| Color Temperature | 2700-6500K |
| Beam Angle | 30° / 60° / 90° / 60°*90° / 70° * 145° |
| Storage Temperature | (- 20 ~ + 55 ) Degrees Celsius |
| Operating Temp | (- 30 ~ + 55 ) Degrees Celsius |
| Warranty | 3 years |
| MOQ | 1PCS |
| Chip | Taiwan (Vendor of Aurora) |
Led street light features
LED street light is an important part of city lighting, traditional street lamps used high-pressure sodium lamp, the overall light low pressure sodium lamp caused a huge waste of energy, therefore, the development of efficient, energy saving, long life, high color rendering index, environmental protection is very important for city street lamp lighting energy-saving significance.
High power LED street light and high pressure sodium lamp is different from conventional light source, high power LED street light with low voltage DC power supply, by the synthesis of GaN based blue LED and yellow fluorescent powder, white LED, with high efficiency, safety, energy saving, environmental protection, long life, fast response speed, high color rendering index unique advantages and can be widely used in city road lighting.
Light emitting diodes (LightEmittingDiode, abbreviated as LED) is a semiconductor pn junction formed with weak electricity can light high efficiency solid-state light source based on the forward bias voltage and the injected current, injected into the P region of the hole and injected into the N region electron in diffusion into the active region after radiation and emit a photon, electric can be directly converted into light energy.
DOB Advantages:
1) Our engineer has 13 Years experience in led lighting field
2) 6 years focus on AC linear led lighting
3) 3nd Generation Linear IC from Top Taiwan Team-Vendor of AURORA Lighting
4) Driverless led lighting already worked 4-3 Years all over the world, failure rate <0.5%, you can sleep well at night because very few complaints
5) Working voltage max 300V, other company max 265V
6) With Over voltage protection, over temperature protection, short circuit protection, over load protection
7) Pass Safety Certification, EMC/EMI
8) 4KVA Surge Protecion on board, 6KVA and 10KVA SPD available
9) 3years warranty
10) Can be work in harsh environment from minus 30 degrees to 50 degrees
Product Details Picture:
